Choosing the right metal for your project can be crucial, especially when it comes to materials like bronze, brass, and copper. Each of these metals has unique properties, grades, and applications that make them suitable for specific uses. This article will provide an in-depth look at these metals, comparing their characteristics and helping you make an informed decision for your machining projects.
Bronze is primarily an alloy of copper and tin, typically composed of about 88% copper and 12% tin. Trace amounts of other metals, such as aluminum, manganese, phosphorus, and silicon, may also be present in the alloy.
Bronze is widely used in applications requiring durability and resistance to wear. Common uses include:
Brass is an alloy of copper and zinc, with varying zinc content to produce different properties. It is known for its malleability, making it easy to work with, and its attractive gold-like appearance. Brass is also relatively resistant to corrosion and has moderate electrical and thermal conductivity.
Copper is a pure metal with outstanding electrical and thermal conductivity. It is highly malleable and ductile, making it easy to shape and form. Copper also has excellent corrosion resistance, developing a protective green patina over time when exposed to the elements.
Each of these metals has unique properties and characteristics that make them suitable for different applications. To help you understand the differences, we have created a detailed comparison table.
| Property | Brass | Bronze | Copper |
|---|---|---|---|
| Element Composition | Copper (55-95%) + Zinc | Copper (80-90%) + Tin + Other Metals | Pure Copper (99%+) |
| Color | Can range from red to gold in colour depending on the level of zinc added to the alloy | Dull gold | Orange-tinted red |
| Corrosion Resistance | Intermediate | Very Good | Very Good |
| Yield Strength | 95 to 124 MPa | 125-800 MPa | 33.3 MPa |
| Tensile Strength | 338 to 469 MPa | 350 to 635 MPa | 210 MPa |
| Thermal Conductivity | 109-121 W/mK | 24-108 W/mK | 210-400 W/mK |
| Electrical Conductivity | High (but less than copper) | Moderate (lesser than brass and copper) | Very High |
| Hardness | 65-95 BHN | 60-290 BHN | 60-95 BHN |
| Machinability | Good to Excellent | Fair to Good | Fair |
| Weldability | Good | Poor | Excellent |
| Melting Point | 900-940°C | 1085-1130°C | 1085°C |
Copper is a naturally occurring metal and the only one among the three that is not an alloy. Brass is an alloy of copper and zinc, often including elements like aluminum, silicon, iron, and manganese to enhance its properties. Bronze, primarily composed of copper and tin, may also contain zinc, phosphorus, nickel, and aluminum, providing excellent wear resistance and durability. Thus, while copper is used in its pure form, brass and bronze are alloys that gain their specific characteristics from their varied compositions.
Brass typically has a pale yellow color with a metallic luster, making it visually appealing for decorative applications. Bronze appears reddish-brown and has a metallic luster, often used in sculptures and industrial applications. Copper has a distinctive orange-red color with a metallic luster, developing a green patina over time when exposed to the elements.
Bronze offers the highest level of corrosion resistance among the three metals, developing a protective mottled patina that is especially effective against seawater corrosion, making it ideal for marine applications. Copper also exhibits impressive corrosion resistance by forming a green patina that protects it over time, though not as effectively as bronze. Brass, while still offering moderate corrosion resistance, is less effective in saltwater environments compared to bronze and copper. Therefore, for applications requiring high corrosion resistance, bronze is the best choice, followed by copper, with brass being the least resistant.
Bronze offers the highest strength among the three metals, with a yield strength range of 125-800 MPa and a tensile strength range of 350-635 MPa. This makes bronze ideal for applications requiring superior strength and resistance to metal fatigue. Brass has a moderate yield strength of 95-124 MPa and a tensile strength of 338-469 MPa, providing good durability for many structural applications. Copper has the lowest strength, with a yield strength of 33.3 MPa and a tensile strength of 210 MPa, making it less suitable for high-stress applications but still valuable for its excellent conductivity and malleability. Therefore, for projects requiring high strength, bronze is the best choice, followed by brass, with copper being the least strong.
In terms of thermal and electrical conductivity, copper is the superior choice, with the highest thermal conductivity (210-400 W/mK) and 100 percent electrical conductivity. Brass has moderate thermal conductivity (109-121 W/mK) and about 28 percent of copper's electrical conductivity. Bronze has the lowest thermal conductivity (24-108 W/mK) and about 15 percent of copper's electrical conductivity, due to its alloying elements. Therefore, for applications requiring excellent thermal and electrical conductivity, copper is the best option, followed by brass, with bronze being the least conductive.
Following the values on the Brinell hardness scale, the hardness score for bronze typically ranges from 60 to 290, while the score for brass is between 55 and 95. Copper has a Brinell hardness score of around 35-45, making it the softest among the three metals. While bronze is harder than brass and copper, it can be more brittle and susceptible to fracturing under certain conditions. Therefore, bronze provides higher hardness but with a trade-off in brittleness compared to the softer and more malleable brass and copper.
Brass is the most machinable of the three metals, making it easy to work with in various manufacturing processes. Copper also offers good machinability and flexibility but can be somewhat sticky when machined. Bronze is the least machinable due to its higher hardness and rigidity, which makes it more challenging to work with.
Copper, especially deoxidized and oxygen-free types, offers superior weldability, typically using TIG and MIG methods. Brass is also weldable with TIG, MIG, and silver soldering, with lower zinc content alloys being more weldable. Bronze, while weldable, can be more prone to cracking under stress, making specialized techniques like SWAM often necessary.
Bronze is the most durable, offering high strength and corrosion resistance, making it less prone to bending. Copper is strong and flexible, with good resistance to cracking and scratching. Brass is the least durable, being more susceptible to splitting and cracking and having lower corrosion resistance than bronze and copper.
Brass has a melting point of 900-940ºC, and bronze melts at 950-1050ºC, making them more formable. Copper, with its higher melting point of 1085ºC, is less formable. Therefore, brass and bronze are easier to shape and form than copper.
Selecting the appropriate metal alloy is essential for the success of any design or manufacturing project. Copper, brass, and bronze each offer unique advantages, such as electrical and thermal conductivity, corrosion resistance, and strength. However, the distinct characteristics of each metal make them suitable for different applications. Here are some key factors to consider when selecting between these versatile metals.
Pure oxygen-free copper offers the greatest flexibility, ductility, and conductivity among the three metals. Copper is highly flexible with excellent electrical and thermal conductivity, while bronze and brass offer better machinability.
Brass is the most suitable for general applications due to its malleability, ease of casting, relative affordability, and low friction. It is ideal for decorative components, items frequently touched by people (like doorknobs), and food-grade surfaces that require anti-bacterial or anti-microbial properties.
Bronze is best suited for tools and equipment intended for marine environments due to its high resistance to corrosion in saltwater and sea environments. Its durability and hardness make it capable of withstanding the stress of marine applications.
The cost of each of these metals varies due to the availability of several alloys. Brass is the most budget-friendly option, thanks to its high zinc content, making it an inexpensive choice. Bronze is moderately priced, coming in as the second most affordable option. Copper, however, is the most expensive of the three metals.
